Name: Wedge for precise polar alignment
Brand: Move-Shoot-Move Rotator
SKU: XIEPI3
Price: 97.88 USD
Availability: InStock

$109.98 $97.88

Options

Separate Wedge

Wedge+ 360° Panning Base

Free worldwide shipping above $99

[{"id":47097611747545,"title":"Separate Wedge","option1":"Separate Wedge","option2":null,"option3":null,"sku":"XIEPI3","requires_shipping":true,"taxable":false,"featured_image":{"id":47002681835737,"product_id":4656368713805,"position":6,"created_at":"2026-01-09T18:16:13+08:00","updated_at":"2026-01-09T18:17:58+08:00","alt":null,"width":2360,"height":2360,"src":"\/\/www.moveshootmove.com\/cdn\/shop\/files\/separatewedge.png?v=1767953878","variant_ids":[47097611747545]},"available":true,"name":"Wedge for precise polar alignment - Separate Wedge","public_title":"Separate Wedge","options":["Separate Wedge"],"price":9788,"weight":500,"compare_at_price":10998,"inventory_management":"shopify","barcode":"","featured_media":{"alt":null,"id":38444009128153,"position":7,"preview_image":{"aspect_ratio":1.0,"height":2360,"width":2360,"src":"\/\/www.moveshootmove.com\/cdn\/shop\/files\/separatewedge.png?v=1767953878"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":47097611780313,"title":"Wedge+ 360° Panning Base","option1":"Wedge+ 360° Panning Base","option2":null,"option3":null,"sku":"kb_Wedge_Panbase","requires_shipping":true,"taxable":false,"featured_image":{"id":46132107509977,"product_id":4656368713805,"position":7,"created_at":"2025-08-22T09:33:44+08:00","updated_at":"2026-01-09T18:16:44+08:00","alt":null,"width":1080,"height":1080,"src":"\/\/www.moveshootmove.com\/cdn\/shop\/files\/COMBO_1.png?v=1767953804","variant_ids":[47097611780313]},"available":true,"name":"Wedge for precise polar alignment - Wedge+ 360° Panning Base","public_title":"Wedge+ 360° Panning Base","options":["Wedge+ 360° Panning Base"],"price":10778,"weight":500,"compare_at_price":10998,"inventory_management":"shopify","barcode":"","featured_media":{"alt":null,"id":37644695011545,"position":8,"preview_image":{"aspect_ratio":1.0,"height":1080,"width":1080,"src":"\/\/www.moveshootmove.com\/cdn\/shop\/files\/COMBO_1.png?v=1767953804"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

HANDLE TIME

All orders will be scheduled for shipment in 1 to 3 business days, excluding holidays.

COUNTRIES

We ship worldwide.

WAREHOUSES

Currently, we have 4 warehouses.

🇺🇸 US warehouse, for our US users, parcel usually arrives in 1-7 days.

🇪🇺 EU warehouse, for most EU countries, parcel usually arrives in 1-7 days.

🇦🇺 AU warehouse, for our Australia and New Zealand users, parcel usually arrives around 1-7 days.

🇨🇳 CN warehouse, for all countries, parcel arrives in 4-7 or 8-20 days, please check below for details.

For more information, click here to check more.

DIMENSIONS & WEIGHTS

Wedge:

Total height: 77.5 mm
Base diameter: 58.8mm
Net weight: 0.70 pounds (318.2 g)
Maximum load: 11 lbs (5 kg)
Arca Swiss Plate: Included
Screw Hole on the bottom: 3/8 Screw Hole

GENERAL TECHNICAL DATA

Color: Black
Material: CNC-Milled Aluminum Alloy
Tilting Adjustment: 0°-60°
Compatibility: Any Rig with ARCA Swiss on the Bottom, for example, MSM Rotator, MSM NOMAD, Seestar S30, Seestar S50, Dwarf 2, Dwarf 3 and so on.

To attach the Seestar to the wedge, you'll need to obtain a 3/8'' to 1/4 screw adapter (optional) or 1/4" female - to - 3/8" male conversion adapter （optional）. For more detailed information, please refer to this video guide:

Panning Base

Diameter of the base: 60mm

Height:19mm

Weight: 13.5g

Scale markings:

Each major gap represents 15°
Each minor mark represents 2.5° (15° divided into 6 equal parts)

⚠️ Compatibility note:

The adjustment knob of the panning base extends slightly below the base, so it may not be compatible with tripods that have a large, flat mounting surface, as the knob could come into contact with the tripod.

Description of Wedge

The MSM Wedge is designed for precise polar alignment, similar to a ballhead but with finer adjustment capabilities. It features four knobs and one handle, for multi-directional adjustments, allowing you to set your tracker or camera at various angles. On top of the Quick-Release Plate has a standard 1/4"-20 threaded screw so that you can attach anything with a 1/4"-20 threaded screw upon it.

How to set up NOMAD with MSM wedge:

How to use it?

Knob A Lock or Unlock the Quick-Release Plate on the top
Knob B & Handle:
- Knob B controls the altitude adjustment.
- The handle locks and unlocks the altitude adjustment when turned in the direction of Knob B or the opposite direction, respectively. Simply pull the handle out to adjust its direction and this action will not affect the locked or unlocked status.
Knob C & Knob D adjust the azimuth for precise left and right movements in tiny increments.
Knob E Factory screw for base connection only, no user function

Wedge + Panning Base. Why this combo?

The panning base lets you rotate your gear freely in any direction without moving the tripod—perfect for quick setup, especially in unfamiliar locations.
The wedge provides fine-tuned, precise adjustments, making polar alignment smoother and more accurate.
Together, they simplify both coarse and fine alignment, saving you time and effort in the field.
